Fiber Transmitter - - ETV
Product details of the fiber transmitter
Quick Overview
All the processes of ETV fiber transmitter are conducted smoothly with advanced facility manned with highly qualified professionals. Its quality is strictly checked by quality inspection department from the raw material to the shipment process. We have professional team to help customers to solve the problems about fiber transmitter timely.
Product Information
ETV will present you fiber transmitter's details in the following section.
ETV-OSN155-CATV(L) optic a |transmitter，adopting an internal isolated DFB laser diode module, is designed to meet the challenge of delivering 106 PAL B/G channels along with video and data over HFC network,intelligent monitor display and reliable power supply avaliable.
● Operating bandwidth: 862MHz platform, optical output power from 2~10mW
● High performance DFB laser with internal isolation to provide optimum signal quality
● Advanced pre-distortion circuit, with excellent CSO and CTB performance.
● AGC circuit available, providing constant input RF level to laser to ensure optimum laser
output.
● Microprocessor automatically controls output power (APC), modulation ratio (AMC).
● Front LED panel to provide display of major parameter of operating status: optical .
output power, operating current, input RF level，modulation ratio status.
● High eficiency and stability switching power supply.
|
Optical parameters |
Parameter |
Value |
|
Wave length (nm) |
1310+20 |
|
|
Output Optical Power |
2~10mW |
|
|
CNR (dB) |
》51 |
|
|
CTB (dB) |
》65 |
|
|
CsO (dB) |
》60 |
|
|
Connector |
SC/APC |
|
|
RF parameters |
Bandwidth (MHz) |
45~862 |
|
Input Impedance (Ω) |
75 |
|
|
AGC Accuracy (dB) |
（±5/±0.3） |
|
|
Input Return Loss (dB) |
》16 |
|
|
Input Level Range (dBμV) |
80±5 |
|
|
Level adjustable range (dB) |
0~10 |
|
|
In-band Flatness (dB) |
±0.5 |
|
|
Level of Test Point (dBμV) |
Input Level to laser -20dBuV |
|
|
General parameters |
Input voltage(V) |
AC220V and AC60V |
|
Current Consumption (A) |
0.25 |
|
|
Operating Temperature (C) |
0~+50 |
|
|
Dimensions (mm) |
194(W)x147(D)x44(H) |
