Company Advantages
· In the production of ETV digital video signals, only the superior quality raw materials are adopted.
· With the adoption of sophisticated testing equipment, the product is guaranteed to be of zero-defect quality.
· Beijing Yite Video Technology Co., Ltd.'s sales performance has been steadily increasing these years.
ETV-OSN155-CATV(L) optic a |transmitter，adopting an internal isolated DFB laser diode module, is designed to meet the challenge of delivering 106 PAL B/G channels along with video and data over HFC network,intelligent monitor display and reliable power supply avaliable.
● Operating bandwidth: 862MHz platform, optical output power from 2~10mW
● High performance DFB laser with internal isolation to provide optimum signal quality
● Advanced pre-distortion circuit, with excellent CSO and CTB performance.
● AGC circuit available, providing constant input RF level to laser to ensure optimum laser
output.
● Microprocessor automatically controls output power (APC), modulation ratio (AMC).
● Front LED panel to provide display of major parameter of operating status: optical .
output power, operating current, input RF level，modulation ratio status.
● High eficiency and stability switching power supply.
|
Optical parameters |
Parameter |
Value |
|
Wave length (nm) |
1310+20 |
|
|
Output Optical Power |
2~10mW |
|
|
CNR (dB) |
》51 |
|
|
CTB (dB) |
》65 |
|
|
CsO (dB) |
》60 |
|
|
Connector |
SC/APC |
|
|
RF parameters |
Bandwidth (MHz) |
45~862 |
|
Input Impedance (Ω) |
75 |
|
|
AGC Accuracy (dB) |
（±5/±0.3） |
|
|
Input Return Loss (dB) |
》16 |
|
|
Input Level Range (dBμV) |
80±5 |
|
|
Level adjustable range (dB) |
0~10 |
|
|
In-band Flatness (dB) |
±0.5 |
|
|
Level of Test Point (dBμV) |
Input Level to laser -20dBuV |
|
|
General parameters |
Input voltage(V) |
AC220V and AC60V |
|
Current Consumption (A) |
0.25 |
|
|
Operating Temperature (C) |
0~+50 |
|
|
Dimensions (mm) |
194(W)x147(D)x44(H) |
Company Features
· Beijing Yite Video Technology Co., Ltd. is an real expert in digital video signals industry.
· Applying the high technology is conducive to the efficient production of digital video signals. ETV strongly emphasizes the importance of applying high technology to improve production efficiency.
· We have a significant commitment to our customer satisfaction. We also make the best practice decisions in every facet of our business.
Product Comparison
Our digital video signals has the following advantages over similar products.
